Plate evaporator SWEP V120THx50
Plate evaporator SWEP V120THx50
Price without VAT: 1,100.00 € (Price with VAT: 1,331.00 €) in 3 days Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 60 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx50. |
| Recommended max. flow 1): | 10.5 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 131 mm |
| Related products: | Insulation: HVAC 120Tx60, Ref 120Tx60. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 34.5 kg |
| Product sheet: | V120TH.pdf  |
| Item No. 2): | | - | V120THx50/1P-SC-S | | 14172-050*1 | V120THx50/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx50/1P-SC-E | | - | V120THx50/1P-NC-S | | - | V120THx50/1P-NC-M |
|
| | |
| Notes: | Click to expand notes |
| 1) | The maximum recommended flow is calculated for water to limit pressure losses to 30 kPa. Also the flow velocity at the inlet to the exchanger is kept under 5.5 m/s to prevent erosion from water. The pressure losses increase proportionally to the square of the flow rate. |
| 2) | SC-Y intermediate pressure: for water/water use (approx. 20 bar)
SC-S standard pressure: for water/water use, some refrigerants (approx. 30 bar)
SC-M medium pressure: for refrigerants (approx. 48 bar)
SC-F intermediate pressure: for refrigerants (approx. 50 bar)
SC-H high pressure: for refrigerants (approx. 55 bar)
SC-D, SC-E higher pressure: for CO2 (approx. 55 bar)
SC-U ultra high pressure: for CO2 (approx. 100 bar)
SC-S: plates AISI 316, copper brazing
NSC-M: plates AISI 316, cover plates AISI 304, copper brazing
NC-S: plates AISI 304, copper brazing
SN-S: plates AISI 316, nickel brazing
MC-S: plates SMO 254, copper brazing
SPS-S: plates AISI 316, AISI 316 brazing (All Steel) |
Plate evaporator SWEP V120THx100
Plate evaporator SWEP V120THx100
Price without VAT: 1,740.00 € (Price with VAT: 2,105.40 €) availability on request Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 120 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx100. |
| Recommended max. flow 1): | 19 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 245 mm |
| Related products: | Insulation: HVAC 120Tx100, Ref 120Tx140. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 55 kg |
| Product sheet: | V120TH.pdf |
| Item No. 2): | | - | V120THx100/1P-SC-S | 14172-100*2 | V120THx100/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx100/1P-SC-E | | - | V120THx100/1P-NC-S | | - | V120THx100/1P-NC-M |
|
| | |
Plate evaporator SWEP V120THx40
Plate evaporator SWEP V120THx40
Price without VAT: 970.00 € (Price with VAT: 1,173.70 €) availability on request Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 50 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx40. |
| Recommended max. flow 1): | 8 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 110 mm |
| Related products: | Insulation: HVAC 120Tx40, Ref 120Tx60. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 30.5 kg |
| Product sheet: | V120TH.pdf |
| Item No. 2): | | - | V120THx40/1P-SC-S | | 14172-040*1 | V120THx40/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx40/1P-SC-E | | - | V120THx40/1P-NC-S | | - | V120THx40/1P-NC-M |
|
| | |
Plate evaporator SWEP V120THx60
Plate evaporator SWEP V120THx60
Price without VAT: 1,230.00 € (Price with VAT: 1,488.30 €) availability on request Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 70 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx60. |
| Recommended max. flow 1): | 12.5 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 155 mm |
| Related products: | Insulation: HVAC 120Tx60, Ref 120Tx60. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 38.5 kg |
| Product sheet: | V120TH.pdf |
| Item No. 2): | | - | V120THx60/1P-SC-S | | 14172-060*1 | V120THx60/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx60/1P-SC-E | | - | V120THx60/1P-NC-S | | - | V120THx60/1P-NC-M |
|
| | |
Plate evaporator SWEP V120THx70
Plate evaporator SWEP V120THx70
Price without VAT: 1,360.00 € (Price with VAT: 1,645.60 €) in 3 days Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 80 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx70. |
| Recommended max. flow 1): | 14.5 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 177 mm |
| Related products: | Insulation: HVAC 120Tx80, Ref 120Tx140. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 43 kg |
| Product sheet: | V120TH.pdf |
| Item No. 2): | | - | V120THx70/1P-SC-S | | 14172-070*1 | V120THx70/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx70/1P-SC-E | | - | V120THx70/1P-NC-S | | - | V120THx70/1P-NC-M |
|
| | |
Plate evaporator SWEP V120THx80
Plate evaporator SWEP V120THx80
Price without VAT: 1,490.00 € (Price with VAT: 1,802.90 €) in 3 days Connections: solder ø22U and ø42U + 2x 1 1/2" ISO G ext. thread (combo) |
| Typical use: | A long, highly efficient evaporator that can be used with many refrigerants (capacity about 90 kW). For heat pumps, refrigeration or as an economizer. Also available as P120THx80. |
| Recommended max. flow 1): | 16 m3/h |
| Brazing material: | copper |
| Model version: | plate exchanger from stainless steel (AISI 316) |
| Dimensions (H × W × D): | 525 × 243 × 200 mm |
| Related products: | Insulation: HVAC 120Tx80, Ref 120Tx140. Welding sleeve: 1 1/2" to DN32. |
| Testing pressure: | 69 bar |
| Weight: | 47 kg |
| Product sheet: | V120TH.pdf |
| Item No. 2): | | - | V120THx80/1P-SC-S | | 14172-080*1 | V120THx80/1P-SC-M 22U(27)+42U(27)+2x1 1/2"&35.1(27) | | - | V120THx80/1P-SC-E | | - | V120THx80/1P-NC-S | | - | V120THx80/1P-NC-M |
|
| | |
